Pet Bottle Injection Moulding Die

Get a Price/Quote

MOQ : 1 Unit

Pet Bottle Injection Moulding Die Specification

Product Type
Injection Moulding Die

General Use
PET bottle manufacturing

Material
High-grade steel (typically H13, P20 or stainless steel)

Type
Injection Mould

Style
Customized as per bottle design

Capacity
Varies as per machine capability

Weight (kg)
Depends on cavity size (typically 50-150 kg)

Computerized
No

Automatic
Yes

Control System
Mechanical/manual with hydraulic/electric support

Clamping Force
Recommended 80-150 ton (depends on mould size & machine)

Mold Thickness
Approx. 150-220 mm

Ejector Stroke
40-80 mm

Ejector Force
Standard (as per injection machine)

Injection Rate
Depends on injection machine & shot size

Injection Pressure
Standard (depends on resin and machine)

Screw Diameter
32-50 mm recommended

Screw Torque
Depends on machine

Tie Bar Size
Varies (refer to injection machine)

Screw Stroke
80-120 mm

Opening Stroke
Approx. 200-300 mm

Heating Power
Standard (as per die size & machine)

Pump Pressure
Standard (as per injection machine)

Voltage
Depends on machine; die itself doesnt have voltage requirement

Dimension (L*W*H)
Custom, e.g. 300 mm x 250 mm x 210 mm

Feature
Long service life, precise cavity design, corrosion resistance

Color
Metallic Grey

Maintenance
Requires routine cleaning and lubrication

Cooling System
Integrated water channels for rapid cooling

Design Service
Available as per customer bottle drawings/specs

Mould Life
500,000 - 1,000,000 shots (with proper maintenance)

Compatible Resin
PET (Polyethylene Terephthalate)

Surface Finish
Polished for high clarity PET bottles

Runner System
Cold runner

Number of Cavities
2 (Twin cavity design as shown)

Finish Tolerance
0.02 mm

Application
Ideal for mineral water, beverage PET bottle production

Cavity Material
Hardened tool steel for prolonged durability

Pet Bottle Injection Moulding Die Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About Pet Bottle Injection Moulding Die

Jump on this hot-selling Pet Bottle Injection Moulding Die, meticulously engineered as a twin cavity (2-cavity) masterpiece for producing high-clarity PET bottles. Crafted from valorous, hardened tool steel, it boasts enviable durability and a polished surface finish. The integrated water channels ensure rapid cooling, while its precise cold runner technology optimizes every cycle. Reduced mould maintenance is easily attained with proper care. Designed for both mineral water and beverage bottle production, this premium die elevates your manufacturing process to new heights. Custom design services available to match your specifications.

Versatile Applications & Commercial Suitability

Designed for use in commercial PET bottle manufacturing, this moulding die finds its site of application in dynamic environments like mineral water, beverage and industrial bottle plants. Suitable for use with all PET (Polyethylene Terephthalate) compatible injection moulding machines, it supports both high-volume production and bespoke bottle specifications. Manufacturers seeking efficiency, precision, and reliability will appreciate its performance across a range of bottle types, dimensions, and production requirements.

Main Domestic Market, Premium Sample Policy & Convenient Payment Terms

Mainly delivered across India's thriving plastics industry, our Pet Bottle Injection Moulding Die is dispatched promptly to ensure swift project timelines. Premium sample options are available upon request, providing confidence before bulk purchasing. Payment terms are designed to be flexible and client-centric, streamlining your experience from initial order to final delivery. Every die is handled with care, guaranteeing it reaches you in optimal condition, ready for immediate integration into your production line.

FAQ's of Pet Bottle Injection Moulding Die:

Q: How does the integrated cooling system benefit my PET bottle production?

A: The integrated water channels in the moulding die allow for rapid cooling, reducing cycle times and ensuring a high-clarity finish for each PET bottle. This leads to improved efficiency and greater production output.

Q: What is the process for customizing the die design for my specific bottle shape?

A: You can provide your bottle drawings or specifications, and our design service will create a customized mould to precisely match your requirements. The entire process includes consultation, design approval, and final manufacturing for a tailored solution.

Q: Where can this injection moulding die be applied commercially?

A: This die is ideal for use in mineral water, beverage, and commercial PET bottle production facilities that demand precision, reliability, and high throughput in their product lines.

Q: What is the recommended maintenance routine for long service life?

A: Regular cleaning and lubrication are essential. With proper, routine maintenance, you can expect a mould life spanning 500,000 to 1,000,000 shots, ensuring consistent performance over time.

Q: When should the die be replaced or refurbished?

A: The die should be inspected periodically for wear or any drop in bottle quality. If shot count nears the upper range or tolerances slip beyond 0.02 mm, consider refurbishment or replacement.
